P2C New Generation PC Diagnostics Card

Big

Detailed

P2C New Generation PC Diagnostics Card

Qualities and Features:

1. No need to install software.

2. In addition to diagnostics of computer failures, PC diagnostic cards provide real-

time monitoring to CPU running to help you rule out computer crashes and

headaches that
your computer sometimes is normal and sometimes is failed.

Three models are available: manual monitoring, automatic monitoring or

non-monitoring;

3. Thoroughly elimilated "initial code".

4. The small LED display will show “no” when the CPU stops running suddunly

when it's power on or running (such as system got halted when playing

games, viewing the web pages or typing).

5. Unprecedented compatibility. SIS671 series, kind of advanced motherboards,

are not compatible with old version PC Diagnostics cards (2-bit or even 4-bit),

however, our "New Generation Diagnostics Cards", "Kingnostics Cards" and

"Diagnostics & Stability-Test cards" are compatible with them as well.

6. Easy to operate. Manuals in more than 6 languages(only English version is

available now, versions in other languages to be continued).

7. Never stop when the code goes to “26”.

8. The first thing needs to be done is to confirm whether the cpu is working

while repair a computer. For our cards you do not need to look at the power

light, when the small LED display shows "no", it means the CPU doesn't work,

and that will make it much more easier to do repair.

9. Adopt large-scale IC which has compact structure-stable and reliable.

10. Support 80h, 84h and 300h port.
